AP9565
6,750.00฿
Rack PDU, Basic, 1U, 16A, 208/230V, (12)C13
Warranty : 2Y Carry-in
Lead time : 90-120 Day
คำอธิบาย
Rack PDU, Basic, 1U, 16A, 208/230V, (12)C13
Warranty : 2Y Carry-in
Lead time : 90-120 Day
รายละเอียด
No matter your requirements, APC by Schneider Electric has one of the widest PDU selections around the globe with an array of power connections, voltages, amperages, and cord lengths. And with over 75% of IT managers choosing APC because of their durability, reliability, and trust, you can rely on our products to provide certainty in a connected world. It provides (12) IEC 60320 C13 outlets to supply power to rack equipment. Acceptable input voltages are 200-230 volts, and power output is 208-230 volts. Power is supplied to the PDU through a IEC 320 C20 plug with a 2.5 meter (8 foot) cord. It occupies zero U of valuable rack space, which allows space for more equipment in the rack. Mounting is easy and does not require additional tools in APC NetShelter Enclosures and most third party racks.
ข้อมูลจำเพาะ
| Presentation | Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (12)C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment. |
|---|---|
| Lead time | Usually in Stock |
| Colour | Black |
|---|---|
| Product or component type | PDU |
| PDU type | Basic |
| Cord length | 2.49 m |
| Number of cables | 1 |
| Provided equipment | Installation guide Rack mounting brackets |
| Input Voltage | 200 V 208 V 230 V |
|---|---|
| Height | 44 mm |
| Width | 447 mm |
| Output Voltage | 208 V 230 V |
| Depth | 57 mm |
| Net weight | 2.05 kg |
| Mounting location | Front Rear |
| Mounting preference | No preference |
| Input Plug Type | IEC 60320 C20 |
| Mounting mode | Rack-mounted |
| Rack units | 1U |
| Mounting position | Horizontal |
| Input current limits | 16 A |
| Load capacity | 3680 VA |
| Network frequency | 50/60 Hz |
| Outlet type and quantity | 12 IEC 60320 C13 |
| Product certifications | cUL listed CE Queensland Australia UL listed VDE |
|---|---|
| Standards | UL 60950 |
| Ambient air temperature for operation | 0…45 °C |
| Relative humidity | 0…95 % |
| Operating altitude | 0…10000 ft |
| Ambient air temperature for storage | -25…65 °C |
| Storage Relative Humidity | 0…95 % |
| Storage altitude | 0…15240 m |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 7 cm |
| Package 1 Width | 46.4 cm |
| Package 1 Length | 22.9 cm |
| Package 1 Weight | 3.632 kg |
| Warranty | 2 years repair or replace |
|---|
